Atom Single phase AC charger 7.3kW with Cable Atom-7kW

SKU A0070230E11R11301 Categories ,

Price:

Original price was: $5,400.00.Current price is: $324.00.

Built-in RCD protection

Low standby power consumption

3 charging modes: Fast, Dynamic, ECO

Real-time load management and demand response

IP54 provides high adaptability

Compatible with all branded EV

Wi-Fi/4G/Ethernet communication

OCPP compliance enables backend system integration

100 in stock

The LIVOLTEK Smart EV Charger is the most cutting-edge smart charger available for wall and column installation. It is compact in size, exquisite in appearance, and easy to install. Thanks to its user-friendly APP, it is easy for users to charge independently and economically. It’s surely the best choice for passenger vehicle owners to charge their vehicles by taking the advantage of the time of use tariff and PV system.

  • Built-in RCD protection
  • Low standby power consumption
  • 3 charging modes: Fast, Dynamic, ECO
  • Real-time load management and demand response
  • IP54 provides high adaptability
  • Compatible with all branded EV
  • Wi-Fi/4G/Ethernet communication
  • OCPP compliance enables backend system integration

Weight

3.7 kg

Dimensions

17 × 40 × 11 cm

Model

A0070230E11

Product Name

Single-phase Residential AC Charger

Input/Output

.

Rated Power

7.3kW

Rated Voltage

230Vac±10%

Rated Frequency

50Hz/60Hz

Current Range

6~32A

Charging Interface Type

Type 2/5m

Specifications of Incoming Cables

3*6mm²

Basic Features

.

User Authorization

Free Charging , MyLivoltek APP (RFID Optional)

Cooling

Natural Cooling

Operating Temperature

-30℃~50℃

Storage Temperature

-40℃~70℃

Operating Humidity

5%~95%R

Operating Altitude

≤2000m

IP Degree

IP54

Dimension (W*H*D)

170*400*110mm

Weight

3.7kg

Way of Installation

Wall Mounting (Column Optional)

Energy Management

Support

Standby Power Consumption

<5W

Other Features

.

Status Indication

3 Color LED

Firmware Upgrade

Local / OTA

Way of Communication

Bluetooth (Wi-Fi & Ethernet / 4G Optional)

Emergency Stop Protection

Support

Save Charging Record When Power Off

Support

Electricity Measurement

Build-in Metering Chip

External Communication

RS485/CAN

Monitoring

My Livoltek Cloud

Protection Function

.

Residual Current Protection

6mA DC RCD Internal

Multiple Protection

With Over Voltage Protection , Under Voltage Protection , Overcurrent Protection , Grounding Protection , Surge Protection , Short Circuit Protection , Fault Self-check and Other Multiple Protection Functions.

Standard

.

EMC

IEC-61851-21-2-2018

Safety

IEC-61851-1-2017
